H59 Brass: Revealing the α/β Microstructure Through Metallographic Preparation

MATERIALS MICROSTRUCTURE

H59 brass is a copper-zinc alloy with a dual-phase microstructure. Reliable metallographic preparation is essential for clearly revealing the distribution and morphology of the α and β phases.

For this sample, TROJAN's preparation workflow combines controlled sectioning, progressive grinding, and fine polishing to help minimize surface damage and achieve consistent results.

01
PROCESS OVERVIEW

Preparation workflow:

01
Cutting: Beta-250 Automatic Cutting Machine with an S20 SiC Cutting Wheel
02
Grinding: P400 → P2500
03
Rough Polishing: SC-JP + 3 μm PD-WT
04
Final Polishing: ZN-ZP + 50 nm SO-A439
05
Etching: FeCl3–HCl solution
02
EQUIPMENT AND CONTROL

Controlled Cutting and Grinding & Polishing

PREPARATION EQUIPMENT

The Beta-250 supports controlled, consistent sectioning, while the Alpha-610 Automatic Grinder & Polisher provides controlled grinding force and programmable preparation steps for repeatable surface quality.

03
MICROSTRUCTURAL OBSERVATION

Revealing the α and β Phases

After etching, the α and β phases can be distinguished more clearly, supporting the evaluation of phase distribution and grain morphology.

H59 brass etched microstructure under metallographic examination Etched – 50× Magnification
H59 brass microstructure showing phase distribution and grain morphology Etched – 100× Magnification
KEY TAKEAWAY

Consistent preparation is the foundation for reliable microstructural evaluation.

#
