GH4169 Nickel-based Superalloy Metallographic Preparation

GH4169 nickel-based superalloy is widely applied in hot-section components of aero-engines, as well as high-temperature load-bearing structural parts for aerospace and energy industries.

Metallographic inspection plays a vital role. It visually evaluates grain size, gamma prime precipitation and harmful phase distribution, closely correlating with material strength, creep and fatigue properties.

GH4169 Metallographic Microstructure 200μm

Strict specimen preparation is required. Samples are ground progressively to eliminate scratches, then finely polished with diamond and oxide suspensions to achieve deformation-free mirror surface. Proper pressure and duration control prevent artificial defects, delivering authentic test data for process optimization and quality assessment.

GH4169 Metallographic Microstructure 100μm

Polishing Procedure

1️⃣ P180 abrasive paper with water cooling
2️⃣ POS disc + 9μm PD-WT suspension
3️⃣ YS-JP disc + 3μm PD-WT suspension
4️⃣ ET-JP disc + 50nm SO-A439 suspension

GH4169 Metallographic Microstructure 50μm

Step 2 can be replaced with P400, P800, P1200 or P2000 abrasive paper

GH4169 Metallographic Microstructure 20μm

#Metallography #GH4169 #NickelAlloy #AerospaceMaterial #SamplePreparation
