GP-2000A Automatic Grinder & Polisher

GP-2000A Automatic Grinder & Polisher

Product Description

GP-2000A is suitable for pre-grinding, grinding and polishing of metal lographic samples. The speed of the machine can be adjusted between 50-1000rpm by the frequency converter, so that the machine has a wider application and is necessary advanced automatic equipment for users to make metallographic samples.

E-mail: [email protected]
Download Contact Us Send E-mail
  • GP-2000A Automatic Grinder & Polisher
  • GP-2000A Automatic Grinder & Polisher
  • GP-2000A Automatic Grinder & Polisher
  • GP-2000A Automatic Grinder & Polisher
  • GP-2000A Automatic Grinder & Polisher

Product Details

Features

1. Digital display the speed;

2. The pressure & time are adjustable;

3. Three programmable preset speeds and timer; Stepless speed-adjustment: 50-1000rpm on grinding disc;

4. 20-200rpm on grinding head;

5. Equip with quick replace grinding disc & multiple specimen holder;

6. Pneumatic multi pressure;

7. One bottle for dosing with manual/auto mode;

8. Can prepare 6 specimen simultaneously.


Technical Parameters





 GP-2000A

Base

Wheel

 Double Wheel

Speed

 50~1000rpm

Direction

 CW/CCW

Power

 750W

Wheel Diameter

 8"-10"(200/250mm)
Head

Force Application

 lndividual

Speed

 20-200rpm

Individual Force

 0.1~0.4mpa

Power

 250W

Dosing System

Auto-dosing

 1bottle
Water Supply

Max. pressure

 <0.3MPa

Pipe dia. on inlet

 OD=Φ8mm

Pipe dia. on outlet

 OD=Φ32mm

Recirculating water tank (optional)

 Optional

Noisy

Measured at 1 meter

 <40dBA

Operating Environment

Tempersture

 -20˚C - 60˚C (-4°F -140°F)

Humidity

 0-95%RH

Dimension

W*D*H

 705*698*663mm

Voltage

 110V 60Hz, 220V 50HZ

Minimum Pressure Required

 6*Φ40mm,3*Φ50mm

Weight

 85kg



Our Advantage

  • High Quality

    Our production capacity can meet the needs of different customers with different purchase quantities.

  • Preferential price

    As a professional China Custom GP-2000A Automatic Grinder & Polisher Manufacturers, We have our own equipment, one-stop production, factory direct sales, high quality and low price.

  • Custom service

    We have a strong and production team, which can develop and produce custom GP-2000A Automatic Grinder & Polisher according to the product description or sample provided by customers.

  • Rich products

    It can meet the development and production of many different industries.
